Beam Movinghead
Ares
Discover the adaptable Ares, a strong lighting option that alters your surroundings.
SKU 8718868788238
1 / 8
Product details
With 60,000 hours of bulb life and 60W Osram RGBW 4in1 LEDs, this fixture provides an astonishing spectrum of color options. You have total control over your lighting with remote on/off control via DMX. The Ares produces breath-taking effects with its razor-sharp 4.5° beam angle, limitless pan and tilt rotation, and incredibly quick, silent movements.
Take advantage of easy features like RDM settings and automated fan speed adjustment, as well as seamless RGBW color mixing, a full range dimmer, several strobe effects, and more. With its compact size and lightweight design, the Ares is easy to install and provides limitless creative possibilities.
Specifications
Light source and output
- Light source
- 60w Osram RGBW 4in1 leds
- Lifetime
- 60.000 hours
Optics
- Beam angle
- 4,5°
Control
- Control
- Remote on/off via DMX
- DMX channels
- 14/16
Connections
- Power connection
- Powercon in and out
Power
- Input voltage
- 100–240 V, 50-60 Hz
- Power consumption (max)
- 100 W
- Power supply
- switching mode power supply
- Power supply
- Electronic auto-ranging
Physical
- Dimensions
- 198 × 144 × 300 mm
- Packing dimensions
- 250 × 200 × 350 mm
- Weight (net)
- 4 kg
- Weight (gross)
- 5 kg
- Rigging
- 1 x Omega brackets with ¼-turn quick locks; Safety rope
- Rigging
- 2 ¼-turn locks
Features
- 1.2 inch OLED display with English/Chinese/French/Spanish menu
- Auto lock
- Flip
- Back-up communicating IC
- Super fast, smooth and silent infinite movement
- RGBW color mixing to create vivid, saturated and uniform color effect
- Two virtual color wheels for color bounce effect
- Full range 0-100% dimmer
- Various strobe
- RDM function to change DMX address, flip display and reverse X/Y
- Software upgrade via DMX
- Hibernation when lost DMX for preset time
- Indicate temperature info of base, arm and lamp
- Fan speed auto change according to temperature
- Heat pipe for cooling system
- X/Y
- Pan & tilt endless rotation
- 16-bit resolution
- Auto repositioning
- 3 phase motor for fast and quiet movement
Documentation
Contact support for the current manual, DMX chart or fixture profile.
Request documentation
