DMX Controller
LIGHT-UP STAND ALONE PRO
2 XLR; 2 Universe; 8 Buttons; Stand-Alone Network Control
SKU 8718868788627
1 / 8
Product details
With the LIGHT-UP Standalone Pro, the ultimate 6-in-1 multiprotocol device created for smooth control of complex lightshows, unleash the power of lighting. This flexible tool is the go-to choice for lighting projects, live performances, and installations of all sizes because it has DMX playback, DMX In/Out, Art-Net Out, sACN Out, Node (Art-Net to DMX decoder), and Splitter capabilities.
Utilize the LIGHT-UP Standalone Pro to streamline your lightshow operations. The controller’s internal memory, which is extensible with an SD card slot and has a capacity of 4mb (4000 steps), may be programmed on a computer to create your captivating displays. Users of any skill level may easily manage the lightshow thanks to its 8 pre-set buttons, which start a continuous symphony of light and color. With the LIGHT-UP Standalone Pro, your go-to tool for crafting memorable lighting experiences, you’ll enjoy precision, adaptability, and control like no before.
Specifications
Power
- Power consumption
- 0.3 ~ 0.5 W
- Power supply
- 5 V to 24 V DC, 0.5A max on DC connectors, 5 V, 0.5A via USB
Physical
- Dimensions
- H: 38 mm(1.49in) / W: 166 mm(6.54in) / D: 97 mm (3.82in)
- Weight (net)
- 0.2 kg (0.44 lbs.)
- Weight (gross)
- 0.41 kg (0.9 lbs.)
- Housing
- Black with 4 mounting slots, ABS Plastic
Protection
- Protection rating
- IP40
- Operating temperature
- – 25 to +70 C°
- Environment
- Indoor
- Storage
- Keep dry
- High-voltage protection
- Yes
- Certifications
- CE, RoHS
Inputs and outputs
- Inputs
- USB 2.0 via Mini USB and Ethernet via RJ3 connector
- DMX outputs
- Up to 1024 on 3 pin XLR (XLR5 optional)
- DMX modes
- 2×512 ,1024 or 512 in/out (PC + Stand Alone)
Processing
- Processor
- 32-bit processor
- Internal memory
- Yes, 4Mb (no SD card required)
- Memory capacity
- 20000 steps with 16 ch., 6000 steps with 512 ch., 3000 steps with1024 ch.
- External memory
- SD card slot (accepts all FAT format, Class 10 SD, up to 256 GB)
Documentation
Contact support for the current manual, DMX chart or fixture profile.
Request documentationProduct support
Contact BSL B.V. about LIGHT-UP STAND ALONE PRO, documentation or service.
Contact support
