Static IP65
BSL Pure Lux
Pure power Pure precision Pure Lux
SKU BSL-PURE-LUX
1 / 6
Product details
The high-end RGB-A-WW blinder that transforms every scene with unmatched color performance.
The BSL Pure Lux sets a new benchmark for modern blinders. Powered by a 550W RGB-A-WW LED engine, it delivers not only massive output but also exceptional color quality with a CRI ≥93, ensuring flawless skin tones and true broadcast-ready performance. The addition of full RGB provides a complete, versatile color spectrum, enabling both natural rendering and powerful creative effects.
Its advanced optical system and 50° beam produce a wide, uniform projection that elevates any live production or studio environment. The lightweight magnesium-aluminum housing, IP65 rating, and flexible DMX/RDM modes make the Pure Lux ready for any professional application.
With optional accessories — including rigging solutions, barndoors, and diffusion — the Pure Lux can be fully tailored to the desired look. Engineered for reliability, maximum visual impact, and pure creative control.
Specifications
Light source and output
- Light source
- Custom COB LED (R 100 W, G 100 W, B 100 W, W 150 W, A 100 W)
- Illuminance
- 12.170 lux @1m / 1.638 lux @3m / 625 lux @5m
- Total LED power
- 550 W RGB-A-WW
- CRI / Color temperature
- Ra ≥ 93 | 2000 K-10000 K
Optics
- Beam angle (50%)
- 50 degrees
- Field angle (10%)
- 87 degrees
Effects
- Strobe
- 0-25 Hz
Control
- Control
- DMX512 / RDM
- DMX channels
- 1 / 5 / 8 / 12 / 17 channels
Connections
- Data connection
- 5 pin XLR in/out
Power
- Input voltage
- 100-240 V AC, 50/60 Hz
- Power consumption
- 120 W constant / 280 W boost
Physical
- Dimensions & weight
- 195 × 145 × 145 mm & 2.35 kg
- Housing
- Magnesium-aluminium alloy
- Cooling
- Active fan cooling
Protection
- Protection rating
- IP65
Documentation
Contact support for the current manual, DMX chart or fixture profile.
Request documentation
